SEBO Air Channel Cover for SOFTCASE CE12 (Gray Black / Orange)

Air leaving the SOFTCASE CE12 nozzle travels a defined channel, and 75120SE is the cover that closes it. SEBO lists it at position 154 with the finish spelled out as gray black and orange, a two-tone moulding that is easy to identify on sight and easy to notice when it is missing.

The cover is a sealing part, not a cosmetic one. With it in place the air follows the route the machine was designed around; with it cracked, distorted or absent, part of the flow escapes along the channel instead of reaching the bag, and the machine feels weak at the nozzle even though the motor is working perfectly well. It is one of the first things to look for on a used machine that has been apart before, because it is easy to break on removal and easy to leave off on reassembly.

Position 154 places it among the other airflow parts in the base: the 259 mm sealing strip is position 153, the bearing pin 156 and the air separator 158. If suction at the floor is down, that whole group deserves a look, since a leak anywhere along the path has the same effect as a leak here.

• Part number: 75120SE
• Component: cover for the air channel
• Finish: two-tone gray black and orange
• Fits: SEBO SOFTCASE CE12 upright vacuum
• Diagram position: 154 on the SOFTCASE CE12 parts list
• Function: closes the air channel so flow stays on its intended route
• Genuine SEBO component, sold individually

The two-tone gray black and orange finish makes this an easy part to identify in a box of used spares, and easy to confirm as the right one before the base goes back together. It fastens into the moulded channel it covers, with no sealant involved.

Found by searching SEBO air channel cover, CE12 air duct cover or SOFTCASE CE12 suction loss parts. Ships in 2-5 business days.
