SEBO Hose Duct for FELIX Premium — Dark Blue

Strong pickup on the carpet with weak pull through the hose is a specific complaint with a specific cause. Air is escaping between the two, and on an Indigo-trim FELIX Premium the first place to look is the short moulded passage behind the hose connection. Part 7090DB is that passage in dark blue.

The duct is the sealed link that carries air from the machine's own hose into the body, and it forms part of the airway rather than sitting alongside it. Split a seam or warp a mating face and the motor simply takes the easiest air available, which is room air pulled in through the break rather than dirt drawn through the tools. Nothing looks wrong from outside while that is happening, and the bag stays suspiciously clean, so the fault gets blamed on a tired motor for months before anyone opens the machine.

Drawn at: SEBO's FELIX exploded diagram puts the hose duct at item 14, showing it in black and arctic white; 7090DB is the same component in dark blue. Its immediate neighbours in the airway are worth checking while you are in there, particularly the hose 7050SB and the retaining ring with spring 7018OR that clamps the hose cuff, drawn at item 27 on the FELIX sheet. Further downstream the pre-motor filter 7012AM sits at item 42 and the exhaust filter at item 41.

• Fitment: SEBO FELIX Premium
• Shade: dark blue, as listed for SEBO's Indigo-trim bodies
• Part number: 7090DB
• Job: sealed passage carrying air from the hose connection into the machine body
• Replace when: the joint whistles, the hose end no longer grips, or a crack is visible at the collar
• Related part numbers: 7050SB hose, 7018OR retaining ring, 7091DB filter cover, 7078GS air duct

Seats in the factory location without cutting or shimming. Genuine SEBO hose duct replacement supplied by an authorized SEBO dealer, shipped in 2-5 business days.
